Wallet Connect V2 support for BitcoinCash

Wallets
#19

Hi all, sorry this is taking a lot longer than anticipated. It’s kind of a “three steps forward, two steps back” exercise where I write an implementation, realize there’s a use-case gap, and then have to redesign and refactor.

To give a brief high-level outline of what I’m going for:

BRIEF OVERVIEW

  1. To help preserve privacy (inc. with HD Wallets) and improve security, the Session established between Service (“Dapp”) and Wallet uses a Sandboxed Keypair generated using sandboxedPrivateKey = hash256(sha256(masterPrivateKey) + sha256(domainName)).
  2. This PoC uses LibAuth templates. In future, these template can be hashed and whitelisted (trusted) by a wallet. For security, the Service (“Dapp”) can only specify inputs and outputs by their corresponding scripts in the provided template (no raw locking/unlocking bytecode allowed).
  3. The Service (“Dapp”) CAN request that the Wallet provides additional UTXOs to automatically meet the Satoshi and Token amounts that are summed in the outputs. In this respect, UTXO selection is done by the Wallet, but the Service can also provide inputs that it knows about.
  4. The Service (“Dapp”) CAN request a Wallet’s UTXOs provided they a) contain tokens and b) access to those token category ID’s have been granted upon Session Negotiation (sessionProperties.allowedTokens as an array of category ids or * for ALL tokens). This allows us to support token-specific use-cases (e.g. a particular NFT as input or more vague Crypto-Exchange use-cases).
  5. To prevent standards fracturing, the underlying RPC’s are intended to be transport agnostic: They should be applicable to HTTP, LibP2P any other transports (not just WalletConnect). Thus, we should be able to use them for a future HTTP-based Payment Protocols, etc.
  6. The hope is that, in future, we will be able to converge with what BitJSON is building. The idea is that a wallet CAN (if the template is natively supported) save the data payloads and use the built-in Wallet UX to execute contract actions. But, for WC, the idea is that the SERVICE (“Dapp”) stores the data associated with a given WC account.
  7. There is currently no support for batching requests (or “actions”): We could build this, but BitJSON is working on something similar (“actions”) and we should probably wait to see what his implementation looks like. These will likely replace specifying the transaction manually. NOTE: This is no longer the case and we will need basic batch/actions support. I’m reaching out to BitJSON to see if he knows approx. what this may look like in his implementation so that migration to it is less painful in future, but am going to use a very rudimentary approach in the meantime.
  8. Type-hinting is currently hacked into a variable’s description field. We want to think a little about how to handle this as they are not always static (e.g. using oracles.cash, we may set a price - but we want that to show depending upon which Oracle was chosen in another variable according to the scaling factor).
  9. Currently, the bch_signTransaction_V0 RPC returns redeem scripts for the compiled outputs, but we want to return resolved variables instead (I think this’ll both simplify things and potentially allow us to support multisig).
  10. Accounts are currently identified by address - but there are some benefits we may gain if we use the Public Key instead (e.g. ability to sign and encrypt messages for another user on a Dapp given their pubkey.)

I really hope I can get a tool that’ll be able to demo most of the above by Monday. Assuming my current approach is versatile enough, I think this is realistic. But, if I bump into another use-case gap, might be a bit longer still (apologies).

If any questions in the meantime, please feel free to ask.

5 Likes
#20

Update here:

4 Likes
#21

So here’s the current state of things:

Pat’s spec simply referred to as “WalletConnect” (WalletConnect + Paytaca Connector interface) has been implemented in 3 BCH wallets: Cashonize, Zapit and Paytaca.
The protocol is used by multiple dapps: Tapswap, CashTokens Studio, Cash-Ninjas mint with a few more in the works

Jim’s spec called “CashConnect” (WalletConnect + CashRPC) has been merged into mainline Cashonize but the spec is still marked as pre-alpha.
CashConnect is used by the BCH Guru price prediction game and by the CashRPC IDE

And then there is still the custom Paytaca Connect which is used by the bitcats and available as a 2nd option in the CashTokens studio. Paytaca connect was used by the Paytaca browser extension and was pioneering wallet connect functionality on BCH. Now it can be phased out, as Pat’s wallet connect spec is more general than for just browser extensions.

5 Likes
#22

Without really knowing too much about it, I was impressed by Pat’s spec, and have been blown away by Jim’s spec, even at this early stage. The Guru beta is amazing. Can’t wait until we have that implemented across the ecosystem, and this is only the early version (a bit of work on just the UI to have more helpful links and info would already be a big step forward).

2 Likes
#23

I maintain a list of BCH walletConnecta apps at Tokenaut.cash, it has been growing steadily through-out 2024, so the protocol is positioned to play an important role on BCH going forward.

There is a 4th wallet with support for BCH Wallet Connect on the way: Electron Cash. It will have WalletConnect support through an EC plugin but this is planned to be merged into the mainline wallet eventually.

In the Elecron Cash group the developer, ‘OPReturn’, wrote:

I think the alpha version for WalletConnect plugin for EC is almost ready. Doing final testings. Hopefully I’ll be able to do a release this week.

3 Likes
#24

There’s now 10 dapps using the BCH WalletConnect protocol

The WalletConnect plugin Electron Cash also has been released in alpha version by now so that means 4 supporting wallets (link to the plugin)

Paytaca Connect is also being deprecated as a separate standard and will shortly be removed from Tapswap and from the CashTokens Studio as a user-option.

This means there is strong standardization of the BCH ecosystem around the WalletConnect standard which is great news for users and developers.

CashScript now also has a WalletConnect guide for contract developers to get started using the standard in their dapps.

3 Likes
#25

has anyone been able to migrate from the deprecated “@walletconnect/modal” library?

1 Like
#26

Cashonize and Selene are using @reown/walletkit and @walletconnect/core:

Selene reference (basically a direct rip from Cashonize adapted for Selene’s architecture):

3 Likes
#27

There’s this recent migration blogpost by Reown for the deprecated @walletconnect/modal library: WalletConnect Modal to Reown AppKit Core - Reown Docs

It seems the new library is @reown/appkit/core and you create the modal with a createAppKit function. The styling of the modal also seems to have changed somewhat.

@kzKallisti those are the libraries on the wallet side, Dagur as an app dev is asking about the libraries for the dapp side (the modal library used to display the walletconnect qr code)

2 Likes
#28

oops my bad, thanks for the correction :sweat_smile:

#29

I have created @bch-wc2/interfaces and @bch-wc2/privkey-connector packages.

@bch-wc2/interfaces formalizes the specced interfaces and allows to import them to create signTransaction requests such as those in cashscript and in mainnet-js (see https://github.com/mainnet-cash/mainnet-js/releases/tag/2.7.7)

@bch-wc2/privkey-connector is a small piece of code which utilizes a private key to sign the WC2 requests locally, it is super important part for local development and automated testing.

See the repository https://github.com/mainnet-pat/bch-wc2

4 Likes
#30

I was able to use the latest WalletConnect/AppKit libraries, not to migrate, but to start a new dApp implementation.

I haven’t tested everything, but pairing, getting the addresses, and signing a transaction already works. It also doesn’t support the custom wallets like Paytaca like the original reference, but I’ll try adding that eventually.

Set up

// config.ts

import type { AppKitNetwork } from "@reown/appkit/networks";
import type { InferredCaipNetwork } from "@reown/appkit-common";
import UniversalProvider from "@walletconnect/universal-provider";
import { AppKit, createAppKit } from "@reown/appkit/core";

export const projectId = process.env.NEXT_PUBLIC_REOWN_PROJECT_ID;

// you can configure your own network
const bch: InferredCaipNetwork = {
  id: "bch",
  chainNamespace: "bch" as const,
  caipNetworkId: "bch:bitcoincash",
  name: "Bitcoin Cash",
  nativeCurrency: { name: "Bitcoin Cash", symbol: "BCH", decimals: 8 },
  rpcUrls: { default: { http: [] } },
};

export const networks = [bch] as [AppKitNetwork, ...AppKitNetwork[]];

let provider: UniversalProvider | undefined;
let modal: AppKit | undefined;

export async function initializeProvider() {
  if (!provider) {
    provider = await UniversalProvider.init({
      projectId,
      metadata: {
        name: "Project name",
        description: "Project description",
        url: "https://example.com",
        icons: ["https://example.com/favicon.ico"],
      },
    });
  }
  return provider;
}

export function initializeModal(universalProvider?: UniversalProvider) {
  if (!projectId) {
    throw new Error("Project ID is not defined");
  }
  if (!modal && universalProvider != null) {
    modal = createAppKit({
      projectId,
      networks,
      /* @ts-expect-error https://docs.reown.com/appkit/next/core/installation#others-networks-appkit-core-2 */
      universalProvider,
      manualWCControl: true,
      features: {
        analytics: true, // Optional - defaults to your Cloud configuration
      },
    });
  }
  return modal;
}


// Provider.tsx
"use client";
import React, {
  useState,
  useEffect,
  PropsWithChildren,
  useContext,
} from "react";
import { initializeProvider, initializeModal } from "./config"; // previous config file
import UniversalProvider from "@walletconnect/universal-provider";

const requiredNamespaces = {
  bch: {
    chains: ["bch:bitcoincash"],
    methods: ["bch_getAddresses", "bch_signTransaction", "bch_signMessage"],
    events: ["addressesChanged"],
  },
};

interface Context {
  provider: UniversalProvider | null;
  session: UniversalProvider["session"] | null;
  isLoading: boolean;
  isInitialized: boolean;
  connect: () => void;
  disconnect: () => void;
  addresses: string[] | null;
}

const AppKitContext = React.createContext<Context>({
  provider: null,
  session: null,
  addresses: null,
  isLoading: false,
  isInitialized: false,
  connect: () => {},
  disconnect: () => {},
});

export const useAppKit = () => useContext(AppKitContext);

export function AppKitProvider(props: PropsWithChildren) {
  const [isInitialized, setIsInitialized] = useState(false);
  const [provider, setProvider] = useState<Context["provider"]>(null);
  const [session, setSession] = useState<Context["session"]>(null);
  const [isLoading, setIsLoading] = useState(false);
  const [addresses, setAddresses] = useState<string[] | null>(null);

  // Initialize the Provider and AppKit on component mount, and check for existing session
  useEffect(() => {
    const init = async () => {
      const dataProvider = await initializeProvider();
      setProvider(dataProvider);
      const modal = initializeModal(dataProvider);

      modal?.subscribeEvents(({ data }) => {
        switch (data.event) {
          case "MODAL_OPEN":
            setIsLoading(false);
          default:
            return;
        }
      });

      if (dataProvider.session) {
        // check if there is a session
        setSession(dataProvider.session);
      }
      setIsInitialized(true);
    };
    init();
  }, []);

  useEffect(() => {
    if (session == null || provider == null || isInitialized === false) return;
    (async () => {
      try {
        const addresses = (await provider.client.request({
          chainId: "bch:bitcoincash",
          topic: session.topic,
          request: {
            method: "bch_getAddresses",
            params: {},
          },
        })) as string[];
        setAddresses(addresses);
      } catch (e) {
        console.error(e);
      }
    })();
  }, [session, provider, isInitialized]);

  useEffect(() => {
    // Handler for when WalletConnect generates a connection URI
    // Opens the AppKit modal with the URI and shows the connecting view
    if (provider == null) return;
    const handleDisplayUri = (uri: string) => {
      const modal = initializeModal(provider);
      modal?.open({ uri, view: "ConnectingWalletConnectBasic" });
    };

    // Handler for when a wallet successfully connects
    // Updates the session state and closes the modal
    const handleConnect = async ({
      session,
    }: {
      session: Context["session"];
    }) => {
      setSession(session);
      const modal = initializeModal(provider);
      await modal?.close();
    };

    const handleDisconnect = async () => {
      setSession(null);
    };

    // Subscribe to WalletConnect events
    provider?.on("display_uri", handleDisplayUri); // Listen for connection URI
    provider?.on("connect", handleConnect); // Listen for successful connections
    provider?.on("disconnect", handleDisconnect);

    return () => {
      provider?.removeListener("display_uri", handleDisplayUri);
      provider?.removeListener("connect", handleConnect);
      provider?.removeListener("disconnect", handleDisconnect);
    };
  }, [provider]);

  const connect = async () => {
    setIsLoading(true);
    try {
      if (!provider) {
        throw new Error("Provider is not initialized");
      }
      await provider.connect({
        namespaces: requiredNamespaces,
      });
    } catch (error) {
      console.error("Failed to connect:", error);
    } finally {
      setIsLoading(false);
    }
  };

  const disconnect = async () => {
    setIsLoading(true);
    try {
      if (!provider) {
        throw new Error("Provider is not initialized");
      }
      await provider.disconnect();
    } catch (error) {
      console.error("Failed to disconnect:", error);
    } finally {
      setSession(null);
      setIsLoading(false);
    }
  };

  return (
    <AppKitContext.Provider
      {...props}
      value={{
        provider,
        session,
        isLoading,
        connect,
        disconnect,
        isInitialized,
        addresses,
      }}
    />
  );
}

Usage

const {
  connect,
  disconnect,
  addresses,
  isLoading,
  isInitialized,
  session
} = useAppKit();

// open modal

connect()

// request transaction signature

await provider.client.request({
  chainId: "bch:bitcoincash",
  topic: session?.topic,
  request: {
    method: "bch_signTransaction",
    params: JSON.parse(stringify(wcTransactionObj)),
  },
});
4 Likes
#31

I built a React library to make wallet integration in Bitcoin Cash dApps effortless, implementing wc2-bch-bcr with the latest version of Reown AppKit (instead of the deprecated walletconnect packages). It’s inspired by RainbowKit and wagmi, which provide a seamless DX.

I aim to bring that DX to BCH dApp development, making wallet connection integration as simple as:

  1. Install the npm package
  2. Set the corresponding provider
  3. Use the features through your app (connect, address, signTransaction, signMessage, etc.)

Just like RainbowKit does.

I’ve shipped a minimal working version of bch-connect, which is already published on npm, thoroughly documented in the repository README, and with a live example using it.

I still need to write test suites, and it likely still contains a lot of bugs and issues. But I’ll be working on improving it and eventually scaling it (for instance, adding support for cashconnect). I’ve never maintained a library before, so any feedback and criticism is very welcome.

The wallets I know currently work fine are Cashonize (web) and Zapit. Paytaca doesn’t work yet, but I don’t know exactly why — I still have to investigate how to make it work.

Here’s a glimpse of how bch-connect looks like:

import { useWallet } from "bch-connect";

export const WalletButtons = () => {
  const { connect, connectError, isConnected, disconnect, tokenAddress } =
    useWallet();

  return (
    <>
      <button onClick={connect}>
        {isConnected ? tokenAddress : "Connect wallet"}
      </button>

      {isConnected && (
        <button title="Disconnect wallet" onClick={disconnect}>
          Disconnect
        </button>
      )}

      {connectError && <p>Error connecting wallet: {connectError.message}</p>}
    </>
  );
};
4 Likes
#32

Wow this is very cool. Our WalletConnect integration on Selene is still quite basic and shaky, so this might actually be extremely useful for us in upgrading that to be a lot cleaner & more robust of an integration.

This is also super useful tooling with BCH BLAZE coming up - I can see a LOT of interest & usage from fresh devs coming into the scene and onboarding straight to WalletConnect with this.

Very excited by this project, great job!

Bug report: Clicking “Connect Wallet” and then “Search Wallets” on the bottom of the pop up modal leads to a perma-loading stalled state.

image1920×1115 134 KB

2 Likes
#33

I’m leaving here some information I’ve gathered while struggling with BCH Connect library, as it could be useful for other developers facing the same or similar issues in their projects.

The problem: While the wallet connection worked correctly in Cashonize web and Zapit with the implementation I made in BCH Connect, Paytaca mobile and Cashonize mobile weren’t working at all. (I’m not including the Paytaca browser extension, as I’ve tested it in all dApps listed in tokenaut.cash and it doesn’t work anywhere. It’s likely a bug in Paytaca’s codebase).

What I’ve found is that Paytaca Mobile and Cashonize Mobile only work with deprecated versions of the @walletconnect/sign-client package. From my testing, they work fine with the version 2.19.1.

So if you are implementing wallet connection in your project, you’ll need to install the deprecated @walletconnect/sign-client@2.19.1 instead of newer versions if you want to support the wallets mentioned above.

I’m currently working to add out-of-the-box support for all of this in BCH Connect, using the latest packages when possible and the deprecated ones when necessary, so developers don’t have to struggle with these kinds of issues. And hopefully, the wallet developers will be able to address these compatibility issues in future updates.

5 Likes
#34

Thanks for a heads up. I am currently working to extract my web3modal+sign-client solution into an npm package with the same structure of hooks so that your reown based solution will become a drop in replacement when all issues will be solved. Will publish my package soonish

3 Likes
#35

Thanks @fran-dv for sharing your findings, just did quite a bit of extra testing with BCH walletconnect myself and want to share my findings

I’ve tested the following 3 walletconnect @walletconnect/sign-client versions

  1. deprecated version using requiredNamespaces (v2.20.0)
  2. deprecated version using optionalNamespaces (v2.21.0)
  3. non deprecated version (v2.21.9)

since Cashonize release v0.5.5 the optionalNameSpaces key is properly supported

first, for me in my walletconnect testing with Cashonize:
Cashonize mobile (v0.5.6) works for all WC lib version
Cashonize dektop (v0.5.6) works for all WC lib version
Cashonize web - chrome desktop - works for all WC lib version
Cashonize web - mobile chrome - works unreliably for all WC lib version

@fran-dv can you share which version of Cashonize mobile you used for testing?
because i cannot replicate the issues you have wit Cashonize mobile

in my testing walletconnect in other BCH wallets

Zapit seems to work with all versions also

Paytaca mobile seems to work only with the deprecated version using requiredNamespaces (v2.20.0)

Selene mobile seems to work only with the deprecated version using requiredNamespaces (v2.20.0)

Hopefully @joemar_taganna and @kzKallisti can take a look at this

So from my testing the only meaningful change seemed to be the difference in optionalNamespaces

not the difference between v2.21.0 (deprecated) and v2.21.9 (supported, non-deprecated)

5 Likes
#36

Thanks everyone for the replies!

@MathieuG you’re absolutely right. Cashonize mobile 0.5.6 works with the latest packages. I didn’t realize I was using a very outdated version of Cashonize; sorry about that. I’ll be more careful next time.

And as you said, the difference that causes the issues is optionalNamespaces. From what I understand, the newer versions that deprecated requiredNamespaces automatically assign them to the optional ones, which leads to the incompatibility.

Thanks again for the feedback. I’ll make sure to be more precise in future tests.

4 Likes
#37

upcoming version of Selene (to be released within next few days) supports optionalNamespaces!

4 Likes
#38

Hello everyone, I just wanted to share a quick update on BCH Connect, if anyone is interested. It’s taking me longer than I expected, but I want to reassure you that I’m still actively working on it and excited about shipping it ASAP.

Lately I’ve had very little free time and have run into some issues, mainly with packages compatibility, trying to make everything just work out of the box. Because of that, I decided to start building a custom UI (similar to RainbowKit, which offers a custom modal) instead of relying on Reown AppKit’s modal, with which, for instance, trying to use custom wallets buttons for cashonize or zapit just don’t work, at least with the version I’ve been working with. This will decouple the connection logic from the UI, making the library easily extensible (e.g. towards the CashConnect spec).

The idea is to get closer to the kind of DX the ETH ecosystem offers, standardizing the process of implementing wallet connections for BCH builders with a good UX UI for users that feels native to the BCH ecosystem.

In my free time I’m working on:

  • The custom UI I mentioned above
  • A modern documentation site for the library (with handy tools such as a CLI like npm create bch-dapp)
  • Improving the codebase and API to make it as simple to use as possible

Adapting the library for non-React apps (Vue, vanilla JS) is on my roadmap.

I’m really excited and eager to ship the first acceptable version, and to avoid spamming here with updates, I created an X account where I’ll announce releases and updates: @fran__dv

2 Likes
